ePMP 2.4 GHz Force 200AR2-25 High Gain Radio (US cord)
Cambium Networks resolves this challenge with a breakthrough
technology solution that delivers superior performance, resiliency
and reach in the most congested environments. The ePMP Force 200
high gain integrated solution enhances range and improves
throughput in high interference environments. ePMP Force 200 is
a completely redesigned solution from Cambium Networks that
combines a highly integrated, high performance radio with a high
gain dish antenna. The radio supports a gigabit Ethernet interface
in order to provide maximum throughput. Operating in the
2.4 and 5 GHz frequency spectrum, the solution brings wireless
broadband connectivity to customers over longer distances and
provides a superior return on investment
FEATURES:
-Cambium Networks’ ePMP Force 200 is designed to operate in high interference environments and provides superior throughput of over 200 Mbps of real user data.
-Configurable Modes of operation ensure robust adaptivity to both symmetrical and asymmetrical traffic while providing high performance and round-trip latency as low as 2 – 3 ms.
-QoS management offers an outstanding quality for triple play services – VoIP, video and data and provides three levels of traffic priority.
-Long deployment range is enabled by a high gain antenna combined with 30 dBm of transmit power.
-This platform can be configured as a Subscriber Module or a high gain PTP radio.
technology solution that delivers superior performance, resiliency
and reach in the most congested environments. The ePMP Force 200
high gain integrated solution enhances range and improves
throughput in high interference environments. ePMP Force 200 is
a completely redesigned solution from Cambium Networks that
combines a highly integrated, high performance radio with a high
gain dish antenna. The radio supports a gigabit Ethernet interface
in order to provide maximum throughput. Operating in the
2.4 and 5 GHz frequency spectrum, the solution brings wireless
broadband connectivity to customers over longer distances and
provides a superior return on investment
FEATURES:
-Cambium Networks’ ePMP Force 200 is designed to operate in high interference environments and provides superior throughput of over 200 Mbps of real user data.
-Configurable Modes of operation ensure robust adaptivity to both symmetrical and asymmetrical traffic while providing high performance and round-trip latency as low as 2 – 3 ms.
-QoS management offers an outstanding quality for triple play services – VoIP, video and data and provides three levels of traffic priority.
-Long deployment range is enabled by a high gain antenna combined with 30 dBm of transmit power.
-This platform can be configured as a Subscriber Module or a high gain PTP radio.
Specifications C024900C161A
| Frequency Range | 2402-2472MHz |
| Gain | 17dBi |
| Physical Layer | 2x2 MiMO/OFDM |
| Ethernet Interfaced | 10/100/1000 BaseT, Compatible with Cambium PoE & Standard PoE pinouts |
| Protocols | Used IPv4, UDP, TCP, IP, ICMP, SNMPv2c, HTTPs, STP, SSH, IGMP Snooping |
| Network Management | HTTPs, SNMPv2c, SSH |
| VLAN | 802.1Q with 802.1p priority |
| Nominal Receive Sensitivity (w/FEC) | @200MHz Channel MCS0 = -92 dBm to MCS15 = -68 dBm (per branch) |
| Nominal Receive Sensitivity (w/FEC) | @40MHz Channel MCS0 = -89 dBm to MCS15 = -65 dBm (per branch) |
| Modulation Levels (Adaptive) | MCS0 (BPSK) to MCS15 (64QAM 5/6) |
| Transmit Power Range | -15 to 30dBm |
| Surge Suppression | 1J |
| Environmental | IP55 |
| Encryption | 128-bit AES |
| Temperature | -22 to 140deg F (-30 to 60deg C) |
| Wind Survival | 90mph (145kmh) |
| Power Consumption | 10W max, 5W |
| Input Voltage | 10 to 30V |
